Midea MDV-D22Q1/N1-D User Manual

One-way Cassette
MCAC-VTSM-2017-01
5
2. Specifications
Model
MDV-D22Q1/N1-D
Power supply
1 phase, 220-240V, 50Hz
Cooling
Capacity
kW
1.8
2.2
Input
W
41
41
Rated current
A
0.24
0.24
Heating
Capacity
kW
2.2
2.6
Input
W
41
41
Rated current
A
0.24
0.24
Indoor fan motor
Model
RPS12N
Type
AC
Input(H/M/L)
W
29.5/26.7/25.0
29.5/26.7/25.0
Capacitor
μF
0.8
Speed (H/M/L)
r/min
1180/955/710
Indoor coil
Number of rows
2
Tube pitch(a) × row pitch(b)
mm
21 × 13.37
Fin spacing
mm
1.5
Fin type
Hydrophilic aluminum
Tube outside dia. and type
mm
Ф7 Inner groove tube
Coil length × height × width
mm
760 × 252.4 × 26.74
Number of circuits
2
Indoor air flow (H/M/L)
m
3
/h
523/404/275
Sound pressure level (H/M/L)
dB(A)
38/34/30
Indoor unit
Dimension (W × H × D)
mm
1054 × 153 × 425
Packing (W × H × D)
mm
1155 × 245 × 490
Net/Gross weight
kg
12.5/16
Panel
Dimension (W × H × D)
mm
1180 × 25 × 465
Packing (W × H × D)
mm
1232 × 107 × 517
Net/Gross weight
kg
3.5/5.2
Refrigerant type
R410A
Throttle
Type
Electronic expansion valve
Design pressure(H/L)
MPa
4.4/2.6
Pipe connections
Liquid pipe
mm
Ф6.35
Gas pipe
mm
Ф12.7
Drain pipe
mm
OD Ф25
Standard Controller
Wireless remote controller
Notes: 1. Nominal cooling capacities are based on the following conditions: return air temperature: 27 ° CDB,19 ° CWB,
outdoor temperature:35 ° CDB, equivalent refrigerant piping: 7.5m(horizontal).
2. Nominal heating capacities are based on the following conditions: return air temperature: 20 ° CDB,
outdoor temperature: 7 ° CDB,6 ° CWB, equivalent refrigerant piping: 7.5m(horizontal)
