Midea MDV-D22Q1/N1-D User Manual

One-way Cassette
MCAC-VTSM-2017-01
7
Specifications
Model MDV-D71Q1/N1-D
Power supply
1 phase, 220-240V, 50Hz
Capacity
kW
7.1
Cooling
Input
W
60
Rated current
A
0.36
Capacity
kW
8
Heating
Input
W
55
Rated current
A
0.36
Model YDK43-4
Type
AC
Indoor fan motor
Input(H/M/L)
W
56.2/40.2/28.7
Capacitor
μF
3
Speed (H/M/L)
r/min
1150/1020/850
Number of rows
2
Tube pitch(a) × row pitch(b)
mm
21 × 13.37
Fin spacing
mm
1.5
Indoor coil
Fin type
Hydrophilic aluminum
Tube outside dia. and type
mm
Ф7 Inner groove tube
Coil length × height × width
mm
955 × 336 × 26.74
Number of circuits
5
Indoor air flow (H/M/L)
m
3
/h
933/749/592
Sound pressure level (H/M/L)
dB(A)
44/41/37
Dimension (W × H × D)
mm
1275 × 189 × 450
Indoor unit
Packing (W × H × D)
mm
1370 × 295 × 505
Net/Gross weight
kg
19.5/23.8
Dimension (W × H × D)
mm
1350 × 25 × 505
Panel
Packing (W × H × D)
mm
1410 × 95 × 560
Net/Gross weight
kg
4/5.4
Refrigerant type
R410A
Throttle
Type
Electronic expansion valve
Design pressure(H/L)
MPa
4.4/2.6
Liquid pipe
mm
Ф9.53
Pipe connections
Gas pipe
mm
Ф15.9
Drain pipe
mm
ODФ25
Standard Controller
Wireless remote controller
Notes: 1. Nominal cooling capacities are based on the following conditions: return air temperature: 27 ° CDB,19 ° CWB,
outdoor temperature:35 ° CDB, equivalent ref. Piping: 7.5m(horizontal)
2. Nominal heating capacities are based on the following conditions: return air temperature: 20 ° CDB,outdoor
temperature: 7 ° CDB,6 ° CWB,equivalent ref. Piping: 7.5m(horizontal)
