R410A Tropical Split Type Technical Manual Installation of Outdoor Units
Installation
129
As shown in Fig-16, leave an interval of 500mm between the outdoor units.
≥
5
0
0
m
m
≥500 mm
M12 foundation bo
l
t
4 screws for 1 unit
Fig-16
The distance of the foundation bolt is shown in Fig-17.
7
5
7
m
m
6
7
1
m
m
1
0
H
P
15×20 rectangular hol
e
Fig-17
