1. Specifications
Model MOV-76CN1-C MOV-76HN1-C MOV-96CN1-C MOV-96HN1-C
Power supply - 380~415V-3N-50Hz 380~415V-3N-50Hz
Ambient temp range
℃
17~52
-7～52
17~52
-7～52
Rated input W 11700 11700 14400 14400
Rated current A 19.3 19.3 23.7 23.7
Noise level dB(A)
65 65 67 67
Compressor
Type - scroll scroll scroll scroll
Qty. - 1 1 1 1
Capacity Btu/h
74500
74500
100000 100000
Input W 6950
6950
9110 9110
Rated current (RLA) A 12.3
12.3
16.6 16.6
Locked rotor Amp (LRA)
A 110 110 110 110
Refrigerant
Type - R410A R410A R410A R410A
Charge g 5400 5400 6000 6000
Fan
Type - Axial fan Axial fan Axial fan Axial fan
Dimension mm
Φ530 Φ530 Φ530 Φ530
Drive type/ motor step - Direct/ Single Direct/ Single Direct/ Single Direct/ Single
Motor input W 310+292 310+292 670+644 670+644
Motor speed rpm
928/942 928/942 1250/1220 1250/1220
Coil
Type - Copper tube and aluminum fin Copper tube and aluminum fin
Tube size mm
Φ7.94 Φ7.94 Φ7 Φ7
No. of rows - 2 2 3 3
Fin per inch FPI
18 18 19 19
Length * height mm
2185*880 2185*880 2179*882 2179*882
Refrigerant
piping
Liquid side/ Gas side mm
Φ9.52/Φ22 Φ9.52/Φ22 Φ9.52/Φ25 Φ9.52/Φ25
Max. pipe length m 50 50 50 50
Max. difference in level
m 30 30 30 30
Connection
wiring
Power wiring mm
2
5×6.0 5*6.0 5*6.0 5*6.0
Signal wiring mm
2
2×1.0 4*1.0 2*1.0 4*1.0
Dimension (W*H*D) mm
1255*700*908 1255*700*908
1255*700*908 1255*700*908
Packing (W*H*D) mm
1320*730*1060
1320*730*1060
1320*730*1060
1320*730*1060
Net/ Gross weight kg
171/190
174/193 185/202 187/204
Shipping Qty per 20'/40'/40'HD pcs
24/54/54 24/54/54 24/54/54 24/54/54
Notes:
1. Nominal cooling capacities are based on the following conditions:
Indoor temp: 27°CDB, 19°CWB; Outdoor temp: 35°CDB; Equi valent refrigerant piping: 7.5m (horizontal)
2. Nominal heating capacities are based on the following conditions:
Indoor temp: 20°CDB; Outdoor temp: 7°CDB, 6°CWB; Equiv alent ref. piping: 7.5m (horizontal)
