Specifications R410A Tropical Split Type Technical Manual
Outdoor Units 90
Model MOV-120CN1-C MOV-120HN1-C
Power supply - 380~400V-3N-50Hz
Ambient temp range
℃
17~52
-7～52
Rated input W 17300 17300
Rated current A 28.6 28.6
Noise level dB(A)
69 69
Compressor
Type - scroll scroll
Qty. - 1 1
Capacity Btu/h
118000 118000
Input W 10862 10862
Rated current (RLA) A 21.4 21.4
Locked rotor Amp (LRA)
A 147 147
Refrigerant
Type - R410A R410A
Charge g 7200 7200
Fan
Type - Axial fan Axial fan
Dimension mm
Φ530 Φ531
Drive type/ motor step
- Direct/ Single Direct/ Single
Motor input W 621+587 621+587
Motor speed rpm
1230/1180 1230/1180
Coil
Type - Copper tube and aluminum fin
Tube size mm
Φ7 Φ7
No. of rows 3 3
Fin per inch FPI
19 19
Length * height mm
1376*880 1376*880
Refrigerant
piping
Liquid side/ Gas side
mm
Φ12.7 / Φ28.6 Φ12.7 / Φ28.6
Max. pipe length m 50 50
Max. difference in level
m 30 30
Connection
wiring
Power wiring mm
2
5*6.0 5*6.0
Signal wiring mm
2
2*1.0 4*1.0
Dimension (W*H*D) mm
1255*908*700 1255*908*700
Packing (W*H*D) mm
1295*1025*700 1295*1025*700
Net/ Gross weight kg
199/215 201/217
Shipping Qty per 20'/40'/40'HD pcs
24/54/54 24/54/54
Notes:
1. Nominal cooling capacities are based on the following conditions:
Indoor temp: 27°CDB, 19°CWB; Outdoor temp: 35°CDB; Equi valent refrigerant piping: 7.5m (horizontal)
2. Nominal heating capacities are based on the following conditions:
Indoor temp: 20°CDB; Outdoor temp: 7°CDB, 6°CWB; Equiv alent ref. piping: 7.5m (horizontal)
