Midea MHC-96HWD1N1 User Manual

MCAC-UTSM-201406 Midea R410A Full DC Inverter Split Type Series Technical Manual
18
1. Specifications
Model
MOVG-96HD1N1-R
Power supply
\
380-415V~, 3Ph, 50Hz
Ambient temp in cooling
°C
15～48
Ambient temp in heating
°C
-15~24
Rated input (Whole units)
W
9,250
Rated current (Whole units)
A
16
Noise level
dB(A)
66
Compressor
Type ×Qty.
\
Inverter scroll ×1
Brand
\
Hitachi
Model
\
E705DHD-72D2YG
Capacity
W
23,250 (@ 60rps)
Input
W
7,150 (@60rps)
Refrigerant oil
ml
500 (FVC68D)
Refrigerant
Type/Charge
\
R410A/10,000g
Fan
Type ×Qty.
\
Axial fan ×1
Motor model
\
WZDK750-38G-7
Brand
\
Panasonic
Motor speed
rpm
730
Coil
Type
\
Copper tube and aluminum fin
Tube size
mm
Ф7
No. of rows
\
3
Fin space
mm
1.5
Tube pitch(a)×row pitch(b)
mm
21×13.37
Coil (W×H)
mm
2,800×798
Number of circuits
\
18
Refrigerant
pipe
Liquid side/ Gas side
mm
Ф12.7/Ф28.6
Max. pipe length
m
50
Max. difference in level
m
30(Outdoor unit down), 25(Outdoor unit up)
Connection
wire
Power wire (Outdoor unit)
\
5×6.0mm
2
Signal wire
\
3×0.75mm
2
Dimension (W×H×D)
mm
948×1,585×968
Packing (W×H×D)
mm
1,010×1,705×1,000
Net/ Gross weight
kg
231/256
Notes:
Nominal cooling capacities are based on the following conditions: Indoor temp: 27°CDB, 19°CWB; Outdoor
temp: 35°CDB; Nominal heating capacities are based on the following conditions: Indoor temp: 20°CDB;
Outdoor temp: 7°CDB, 6°CWB; Equivalent ref. piping: 7.5m (horizontal).

Midea MHC-96HWD1N1 Specifications

General

Brand	Midea
Model	MHC-96HWD1N1
Category	Air Conditioner
Language	English
