Midea R410A Full DC Inverter Split Type Series Technical Manual MCAC-UTSM-201406
7
2. Specifications
Model
MHC-96HWD1N1
Power supply
\
220-240V~, 1Ph, 50Hz
Cooling
Capacity
Btu/h
34,120~90,418~102,360
W
10,000~26,500~30,000
Input
W
2,400~8,200~9,800
EER
W/W
3.23
Heating
Capacity
Btu/h
44,356~90,418~102,360
W
13,000~26,500~30,000
Input
W
3,400~8,000~9,800
COP
W/W
3.31
AEER/ACOP
\
3.106/3.294
Rated input
W
850
Rated current
A
4.5
Indoor air flow
l/s
1,389
Indoor standard ESP (External static pressure)
Pa
0~200
Indoor noise level
dB(A)
56
Refrigerant type
\
R410A
Refrigerant control
\
EXV
Fan
Type
\
Centrifugal fan
Motor model (×Quantity)
\
WZDK750-38GS-W (×1)
Speed (Hi/med/lo)
r/min
1,250/1,160/1,090
Coil
Type
\
Copper tube and aluminum fin
Tube size
mm
Ф9.52
No. of rows
\
4
Fin spacing
mm
1.5
Tube pitch(a)×row pitch(b)
mm
25.4×22
Length× height
mm
1,202×457.2
Number of circuits
\
18
Controller
\
KJR-29B1/BK-E (Wired controller)
Refrigerant pipe (Liquid/ Gas)
mm
Ф12.7/Ф28.6
Drain pipe size
mm
Ф41
Connection wire
Power wire
\
3×2.5mm
2
Signal wire
\
3×0.75mm
2
Dimension (W×H×D)
mm
1,470×510×795
Packing (W×H×D)
mm
1,555×545×875
Net/Gross weight
kg
83/92
Notes:
1. Nominal cooling capacities are based on the following conditions:
Indoor temp: 27°CDB, 19°CWB; Outdoor temp: 35°CDB, 24°C WB;
2. Nominal heating capacities are based on the following conditions:
Indoor temp: 20°CDB, 15°C WB; Outdoor temp: 7°CDB, 6°CWB;
3. Equivalent refrigerant piping: 7.5m (horizontal).
