Midea R410A Full DC Inverter Split Type Series Technical Manual MCAC-UTSM-201406
19
2. Dimension
Front view Left view
(Unit: mm)
Top view
3. Service Space
A
B
C
D
E
Installation space
≥1,500mm
≥2,000mm
≥2,000mm
≥1,500mm
≥8,000mm
