Midea MHC-96HWD1N1 - Page 79

MCAC-UTSM-201406 Midea R410A Full DC Inverter Split Type Series Technical Manual
78
2. Keep the Remote Controller away any liquids.
3. Protect the Remote Controller from high temperatures and exposure to radiation.
4. Keep the indoor receiver out of direct sunlight or the air conditioner may malfunction.
5. Keep controller away from EMI (Electro-Magnetic Interference) supplied by other household
appliances.
2. Wired Controller: KJR-29B1/BK-E (Standard)
KJR-29B1/BK-E
2.1 Wired controller specifications
Model
KJR-29B/BK-E
Power Supply Voltage
5.0V DC
Ambient Temperature Range
-5°C ～43°C
Ambient Humidity Range
RH40%~RH90%
Performance Features
1. Operating mode: Cool, heat, dry, fan and auto.
2. Set the mode through buttons.
3. Indoor setting temperature range: 17°C ~30°C .
4. LCD (Liquid Crystal Display).
5. Easy to installation, connect with indoor unit via the four ports of A, B, C, D
6. Remote receiving function.
