Midea M thermal Mono Engineering Data Book
7.11 HOLIDAY AWAY SETTING Menu
MENU > FOR SERVICEMAN > HOLIDAY AWAY SETTING
The HOLIDAY AWAY SETTING menu settings are used to set the outlet water
temperature to prevent water pipes freezing when away from home in cold
weather seasons. In HOLIDAY AWAY SETTING the following parameters should
be set.
T1S_H.A._H sets the heat pump’s leaving water set temperature for space
heating mode when in holiday away mode.
T5S_H.M_DHW sets the heat pump’s leaving water set temperature for DHW mode when in holiday away mode.
7.12 SERVICE CALL Menu
MENU > FOR SERVICEMAN > SERVICE CALL
In SERVICE CALL the following parameters can be set.
PHONE NO. and MOBILE NO. can be used to set after-sales service contact numbers. If
set, these numbers are displayed to users in MENU > FOR SERVICEMAN > SERVICE
CALL
Use ▼ ▲ to adjust the numerical values. The maximum length of the phone numbers
is 14 digits.
The black rectangle found between 0 and 9 when scrolling up and down using ▼ ▲ is converted to a blank space when
the phone numbers are displayed to users in MENU > FOR SERVICEMAN > SERVICE CALL and can be used for phone
numbers less than 14 digits in length.
7.13 RESTORE FACTORY SETTINGS
MENU > FOR SERVICEMAN > RESTORE FACTORY SETTINGS
RESTORE FACTORY SETTINGS is used to restore all the parameters set in the user interface to their factory defaults.
On selecting YES, the process of restoring all settings to their factory defaults begins and progress is displayed as a
percentage.
Figure 3-7.31: RESTORE FACTORY SETTINGS screens
10 RESTORE FACTORY SETTINGS
All the settings will come back to
factory default.
Do you want to restore factory
settings?
OK CONFIRM
NO YES
Please wait…
5%
10 RESTORE FACTORY SETTINGS
Figure 3-7.29: HOLIDAY AWAY SETTING menu
Figure 3-7.30: SERVICE CALL menu
20°C
20°C
8 HOLIDAY AWAY SETTING
8.1 T1S_H.A._H
8.2 T5S_H.A._DHW
ADJUST
ADJUSTOK CONFIRM
9 SERVICE CALL SETTING
PHONE NO. 0000000000000
MOBILE NO. 0000000000000
