M thermal Mono
202005 19
Part 2 - Engineering Data
2 Dimensions and Center of Gravity
Figure 2-2.1: MHC-V18(22, 26,30)W/D2RN8 dimensions and center of gravity (unit: mm)
304
670
425
670
Midea CAC Confidential
