7 Role of Temperature Sensors in Control Functions
Figure 3-7.1: Location of the temperature sensors on 4~16KW unit systems
Notes:
1. The names and functions of the temperature sensors labelled 1 to 12 in this figure are detailed in
Table 3-6.1.
capillary
Solenoid valve
