M thermal Mono
32 200204
Midea M thermal Mono Service Manual
1 Outdoor Unit Electric Control Box Layout
MHC-V4W/D2N8-B / MHC-V6W/D2N8-B
Figure 4-1.1: Electric control box front view
Main PCB for refrigerant system
Main PCB for hydronic system
Main PCB for refrigerant system
Inverter module
terminal blocks
Midea CAC Confidential
