2 Outdoor Unit PCBs
2.1 Types
M thermal Mono outdoor units have two main PCBs – one for the hydronic system and one for the refrigerant system. The
hydronic system main PCB is the same on all M thermal Mono models.
The locations of each PCB in the outdoor unit electric control boxes are shown in Figures 4-1.1 to 4-1.4 in Part 4, 1
“Outdoor Unit Electric Control Box Layout”.
2.2 Main PCB for Hydronic System
Figure 4-2.1: Outdoor unit main PCB for hydronic system
2 3 4 5 6 7 8 9 10
1
30
29
28
27
26
25
11
12
13
14
15
16
17
18
19
20
21
24 31 23 22
22
