3.4 Wide operation temperature range
No matter in extremely cold winter when outdoor temperature gets as low as -15°C or in hot summer when
temperature is up to 46°C, the Mini VRF system will keep stable performance.
3.5 Flexible piping design
3.6 Space saving design
The Mini VRF units are slimmer and more compact, resulting in significant savings in installation space.
In some large residential and light commercial areas, such as villas, restaurants, usually it need more than one
indoor unit, which in turn requires multiple outdoor units.
Midea's Mini VRF system solves this problem, and retains buildings' original aesthetics.
The longest piping length is 70m
The first branch joint to the
farthest IDUis 20m
The IDUto the nearest
branch joint is 15m
Leveldifference between IDUand ODUis 30m
Leveldifference between IDUs is 8m
