3. Electrical Wiring Diagrams
Indoor and outdoor unit wiring diagram
Indoor Unit Outdoor Unit
IDU Model IDU Wiring Diagram ODU Model ODU Wiring Diagram
MSMABU-09HRDN8-QRD0GW
16022000020169
MOAB30-09HFN8-QRD0GW
16022000019533
MSMABU-09HRDN8-QRD0GW MOX133-09HFN8-QRD0GW
MSMABU-12HRDN8-QRD0GW MOAB30-12HFN8-QRD0GW
MSMABU-12HRDNX-QRD0FGW(GA)
MOX133-12HFN8-QRD0GW
MSMACU-18HRFN8-QRD0GW MOB32-18HFN8-QRD0GW
MSMADU-24HRFNX-QRD0GW MOCA32-24HFN8-QRD0GW
16022000019069
utdoor unit printed circuit board diagram
Outdoor Unit
ODU Model ODU Printed Circuit Board
MOAB30-09HFN8-QRD0GW
17122000040049
MOAB30-12HFN8-QRD0GW
MOX133-09HFN8-QRD0GW
17122000048121
MOX133-12HFN8-QRD0GW
MOB32-18HFN8-QRD0GW
17122000023675
MOCA32-24HFN8-QRD0GW
17122000036588
