DM13-01.01.16en Air-cooled Package
Service manual 25
7.1.4 MTA-96HRN1
Gross Cooling Capacity (kW)
Outdoor DB(°C) 29.40 35.00
Indoor WB(°C) 16.10 19.40 22.80 16.10 19.40 22.80
CFM DB(°C) TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI
2440
23.9 24.9 19.4 8.47 27.4 15.5 8.67 28.8 6.6 8.80 24.2 19.8 8.90 26.2 14.8 9.13 27.5 6.3 9.27
26.7 25.8 22.2 8.49 27.9 18.1 8.69 29.3 12.6 8.82 24.7 22.4 8.92 26.7 17.3 9.15 28.0 12.1 9.29
29.4 26.7 24.2 8.51 28.5 23.4 8.71 29.9 17.8 8.84 25.1 24.2 8.94 27.3 22.3 9.17 28.6 17.0 9.31
32.2 27.6 27.0 8.53 29.1 26.4 8.73 30.5 22.4 8.86 25.6 25.1 8.96 27.8 25.3 9.20 29.2 21.4 9.34
2740
23.9 25.9 20.8 8.67 28.0 16.2 8.87 29.4 6.9 9.00 25.1 21.1 9.10 26.8 15.5 9.33 28.1 6.6 9.47
26.7 26.9 23.3 8.69 28.6 20.2 8.89 30.0 13.1 9.02 25.7 23.8 9.12 27.4 19.4 9.35 28.7 12.6 9.49
29.4 27.8 25.7 8.71 29.1 24.5 8.91 30.5 18.6 9.04 26.2 25.7 9.14 27.9 23.4 9.37 29.2 17.8 9.51
32.2 28.8 27.4 8.73 29.7 27.5 8.93 31.2 23.3 9.07 26.7 26.7 9.17 28.5 26.3 9.40 29.8 22.2 9.54
3000
23.9 26.4 23.0 8.91 28.5 17.8 9.24 29.9 7.7 9.24 25.6 23.5 9.34 27.3 17.1 9.57 28.6 7.4 9.71
26.7 27.4 26.0 8.93 29.1 22.3 9.13 30.5 14.6 9.26 26.2 26.2 9.36 28.0 21.4 9.60 29.2 13.9 9.73
29.4 28.3 27.5 8.95 29.6 27.2 9.15 31.1 20.6 9.28 26.7 26.7 9.38 28.4 26.1 9.61 29.7 19.7 9.75
32.2 29.3 28.7 8.97 30.2 27.5 9.18 31.7 25.8 9.31 27.2 27.2 9.41 29.0 26.3 9.64 30.3 24.7 9.78
3240
23.9 26.9 23.8 9.22 29.0 17.3 9.42 30.3 7.4 9.55 26.4 23.4 9.65 27.8 16.6 9.88 29.1 7.1 10.01
26.7 27.9 26.8 9.24 29.6 21.7 9.44 31.0 14.1 9.57 27.0 25.9 9.67 28.4 20.8 9.90 29.7 13.5 10.04
29.4 28.8 28.0 9.26 30.1 26.2 9.46 31.6 20.0 9.59 27.5 27.5 9.69 28.9 25.1 9.92 30.2 19.1 10.07
32.2 29.8 29.2 9.29 30.7 29.6 9.49 32.2 25.0 9.62 28.0 28.0 9.72 29.5 28.4 9.95 30.8 23.9 10.09
