Air-cooled Package DM13-01.01.16en
26 Service manual
Gross Cooling Capacity (kW)
Outdoor DB(°C) 40.60 46.10 51.70
Indoor WB(°C) 16.10 19.40 22.80 16.10 19.40 22.80 16.10 19.40
22.80
CFM DB(°C) TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI
2440
23.9 22.0 18.0 10.83 23.5 13.3 11.07 24.8 5.7 11.22 20.5 16.8 11.02 22.0 12.4 11.28 23.1 5.3 11.53 19.4 15.9 11.52 20.7 11.7 11.88 21.8 5.0 12.13
26.7 22.4 20.4 10.86 24.0 15.5 11.10 25.3 10.9 11.25 20.9 19.0 11.05 22.4 14.5 11.31 23.6 10.2 11.56 19.8 18.0 11.55 21.1 13.7 11.91 22.2 9.6 12.16
29.4 22.8 22.0 10.89 24.5 20.1 11.13 25.8 15.4 11.28 21.3 20.5 11.08 22.8 18.7 11.34 24.1 14.3 11.59 20.2 19.4 11.58 21.5 17.6 11.94 22.7 13.5 12.19
32.2 23.3 22.8 10.91 25.0 22.7 11.16 26.3 19.4 11.31 21.7 21.3 11.11 23.3 21.2 11.37 24.6 18.1 11.62 20.6 20.2 11.61 22.0 20.0 11.97 23.1 17.0 12.22
2740
23.9 22.6 19.0 11.03 24.1 14.0 11.27 25.4 6.0 11.42 21.1 17.7 11.22 22.6 13.0 11.48 23.7 5.6 11.73 20.0 16.8 11.72 21.3 12.3 12.08 22.4 5.3 12.33
26.7 23.0 21.3 11.06 24.6 17.5 11.30 25.9 11.4 11.45 21.5 19.9 11.25 23.0 16.3 11.51 24.2 10.6 11.76 20.4 18.9 11.75 21.7 15.4 12.11 22.8 10.0 12.36
29.4 23.5 23.0 11.09 25.1 21.1 11.33 26.4 16.1 11.48 22.0 21.5 11.28 23.5 19.7 11.54 24.7 15.1 11.79 20.8 20.4 11.78 22.2 18.6 12.14 23.3 14.2 12.39
32.2 24.0 24.0 11.12 25.6 23.7 11.36 27.0 20.1 11.51 22.4 22.4 11.31 24.0 22.2 11.57 25.2 18.8 11.82 21.3 21.3 11.81 22.6 20.9 12.17 23.8 17.7 12.42
3000
23.9 23.1 21.2 11.27 24.6 15.4 11.66 25.9 6.7 11.66 21.6 19.8 11.46 23.1 14.4 11.72 24.2 6.3 11.97 20.5 18.8 11.96 21.8 13.6 12.32 22.9 5.9 12.57
26.7 23.5 23.5 11.30 25.1 19.3 11.54 26.4 12.6 11.69 22.0 22.0 11.49 23.3 18.1 11.75 24.7 11.8 12.00 20.9 20.9 11.99 22.2 17.1 12.35 23.3 11.2 12.60
29.4 24.0 24.0 11.33 25.6 23.5 11.57 26.9 17.8 11.72 22.5 22.5 11.52 24.0 22.0 11.78 25.2 16.7 12.03 21.3 21.3 12.02 22.7 20.8 12.38 23.8 15.8 12.63
32.2 24.5 24.5 11.36 26.1 23.8 11.60 27.5 22.3 11.75 22.9 22.9 11.55 24.5 22.2 11.81 25.7 20.9 12.06 21.8 21.8 12.05 23.1 21.0 12.41 24.3 19.7 12.66
3240
23.9 23.5 20.8 11.58 25.1 15.0 11.82 26.4 6.5 11.97 22.1 19.5 11.77 23.5 14.1 12.03 24.7 6.1 12.28 21.0 18.6 12.27 22.3 13.3 12.63 23.4 5.7 12.88
26.7 24.0 23.1 11.61 25.6 18.8 11.85 26.9 12.2 12.00 22.5 21.7 11.80 24.0 17.7 12.06 25.2 11.5 12.31 21.4 20.6 12.30 22.7 16.7 12.66 23.8 10.8 12.91
29.4 24.5 24.5 11.64 26.1 22.7 11.88 27.5 17.4 12.03 23.0 23.0 11.83 24.5 21.3 12.09 25.7 16.3 12.34 21.9 21.9 12.33 23.2 20.2 12.69 24.3 15.4 12.94
32.2 25.0 25.0 11.67 26.7 25.6 11.91 28.0 21.7 12.06 23.4 23.4 11.86 25.0 24.0 12.12 26.2 20.3 12.37 22.3 22.3 12.36 23.6 22.7 12.72 24.8 19.2 12.97
Notes:
1. DB = Dry Bulb Temperature (°C), WB = Wet Bulb Temperature (°C)
4. TGC = Total Cooling Capacity (kW)
5. SHC = Sensible Heating Capacity (kW)
6. PI = Power Input (kW)
