Service manual
20
Heating mode OUTDOOR CONDITIONS
Indoor Conditions Pressure
12ºC D
11ºC W
7ºC D
6ºC W
0ºC D
-1ºC W
-4ºC D
-6ºC W
-7ºC D
-9ºC W
-15ºC D
-xºC W
15ºC Pressure( kg/cm
2
) 28.4 27.2 21.6 20.8 20.4 /
18ºC Pressure( kg/cm
2
) 30.8 28.6 24.9 23.1 22.4 /
20ºC Pressure( kg/cm
2
) 31.6 30.4 25.6 24.9 23.5 /
22ºC Pressure( kg/cm
2
) 33.7 31.5 26.8 25.6 24.0 /
9.5 MSC-28CRN1
Cooling mode Outdoor temperature (Dry bulb temp)
Indoor Conditions Pressure 25ºC 30ºC 35ºC 40ºC 45ºC 50ºC
21ºC D15ºC W Pressure( kg/cm
2
) 8.9 9.0 9.2 9.3 9.7 10.3
24ºC D17ºC W Pressure( kg/cm
2
) 9.0 9.2 9.6 9.8 10.3 10.8
27ºC D19ºC W Pressure( kg/cm
2
) 9.3 9.6 9.8 10.3 10.7 11.2
32ºC D23ºC W Pressure( kg/cm
2
) 9.7 10.1 10.3 10.8 11.1 11.6
9.6 MSC-28HRN1
Cooling mode Outdoor temperature (Dry bulb temp)
Indoor Conditions Pressure 25ºC 30ºC 35ºC 40ºC 45ºC 50ºC
21ºC D15ºC W Pressure( kg/cm
2
) 8.9 9.0 9.2 9.3 9.7 10.3
24ºC D17ºC W Pressure( kg/cm
2
) 9.0 9.2 9.6 9.8 10.3 10.8
27ºC D19ºC W Pressure( kg/cm
2
) 9.3 9.6 9.8 10.3 10.7 11.2
32ºC D23ºC W Pressure( kg/cm
2
) 9.7 10.1 10.3 10.8 11.1 11.6
Heating mode OUTDOOR CONDITIONS
Indoor Conditions Pressure
12ºC D
11ºC W
7ºC D
6ºC W
0ºC D
-1ºC W
-4ºC D
-6ºC W
-7ºC D
-9ºC W
-15ºC D
-xºC W
15ºC Pressure( kg/cm
2
) 28.6 27.4 21.8 20.9 20.6 /
18ºC Pressure( kg/cm
2
) 30.9 28.8 25.0 23.3 22.6 /
20ºC Pressure( kg/cm
2
) 31.8 30.6 25.8 25.0 23.7 /
22ºC Pressure( kg/cm
2
) 33.9 31.7 27.0 25.8 24.2 /
