Service manual
- 8 -
MSG-12HR-QC2 MSG-18CR-QB9 MSG-18HR-QB9
Ph-V-Hz
1, 220-240V~,50Hz 1,220-240V~,50Hz 1,220-240V~,50Hz
Capacity W 3400 5000 5000
Input W 1050 1700 1700
Rated current A 4.6 7.5 7.5
EER W/W 3.24 2.94 2.94
Capacity W 3600 ---- 5500
Input W 1050 ---- 1800
Rated current A 4.6 ---- 8.0
COP W/W 3.43 ---- 3.06
A 7 11 11
A224242
Model PH200X2C-4FT3 PH310X2CS-4KU3 PH310X2CS-4KU3
Type Rotary Rotary Rotary
Brand Toshiba GD Toshiba GD Toshiba
Capacity W 3440/3470 5350/5400 5350/5400
Input W 1080/1090 1690/1740 1690/1740
Rated current(RLA) A 5/4.65 7.86/7.65 7.86/7.65
Locked rotor Amp(LRA) A 21.6 34 34
Thermal protector UP3RE0591-T56 Internal Internal
Capacitor uF 35 35 35
Refrigerant oil ml 480 750 750
Model RPG20D RPG25 RPG25
Brand WELLING WELLING WELLING
Input W 49.2 53 53
Capacitor uF 1.5uF/450V 1.5uF/450V 1.5uF/450V
Speed(hi/mi/lo) r/min 1120/900/800 1265/1105/1000 1265/1105/1000
m3/h 600/520/480 800/700/600 800/700/600
dB(A) 39/34/30 41/38/35 41/38/35
Model YDK24-6F YDK53-6C YDK53-6C
Brand Welling Welling Welling
Input W 56 125 125
Capacitor uF 2.5 3 3
Speed r/min 800 800 800
m
3
h
1900 1900 1900
dB(A)545656
g 1120 1870 1870
MPa 2.6 2.8 2.8
Liquid side/ Gas side mm Ф6.35/Ф12.7 Ф6.35/Ф12.7 Ф6.35/Ф12.7
Max. refrigerant pipe length m 10 15 15
Max. difference in level m 5 8 8
℃
17-30 17-30 17-30
℃
-7 - 45 -7 - 45 18-45
m
2
18-26 30-40 30-40
Operation temp
Ambient temp
Application area
Outdoor noise level
Refrigerant type R22
Design pressure
Refrigerant
piping
Indoor air flow (Hi/Mi/Lo)
Indoor noise level (Hi/Mi/Lo)
Outdoor
fan motor
Outdoor air flow
Max. current
Starting current
Compressor
Indoor
fan motor
Model
Power supply
Cooling
Heating
Note:
The noise date is base on hemi-anechoic chamber, during actual operation; these values are normally somewhat
different as a result of ambient condition.
The above design and specifications are subject to change without prior notice for product improvement.
