Model MSG-07HRIN2 MSG-09HRIN2 MSG-12HRIN2
Power supply Ph-V-Hz 1, 220-240V~, 50Hz 1, 220-240V~, 50Hz
1, 220-240V~,
50Hz
Capacity Btu/h 7000 9000 12000
Input W 780 990 1340
Rated current
A
4.8 4.5 5.8
Cooling
EER Btu/w.h 9.0 9.0 9.0
Capacity Btu/h 9000 12000 15000
Input W 940 1240 1560
Heating
Rated current
A
4.4 5.5 6.8
Model BG130X1C-20FZ BG130X1C-20FZ BG130X1C-20FZ
Type Rotary Inverter Rotary Inverter Rotary Inverter
Brand TOSHIBA TOSHIBA TOSHIBA
Refrigeran Type POE POE POE
Capacitor uF No No No
Compressor
Refrigerant oil ml 370 370 370
Model RPG13H RPG13H RPG13C
Brand Welling Welling Welling
Capacitor uF 1.2 1.2 1.5
Indoor fan
motor
Speed(hi/mi/lo) r/min 1050/950/750 1100/1000/800 1060/900/800
Indoor air flow (Hi/Mi/Lo) m3/h 500/410/320 520/430/330 560/460/380
Indoor noise level (Hi/Mi/Lo) dB(A) 35/32/26 36/32/26 36/32/26
Model YDK23-6-3 YDK23-6-3 YDK23-6-3
Brand Welling Welling Welling
Outdoor fan
motor
Capacitor uF 2.5 2.5 2.5
Outdoor noise level dB(A) 51 51 53
Refrigerant type R407C g 800 800 1150
Liquid side/ Gas side mm Ф6.35/Ф9.53 Ф6.35/Ф9.53 Ф6.35/Ф12.7
Max. pipe length m 10 10 10
Refrigerant
piping
Max. in level m 5 5 5
Operation temp ℃ 17-30 17-30 17-30
Ambient temp ℃ -15-45 -15-45 -15-43
Application area m2 14-18 18-24 20-30
Note:
The noise date is base on hemi-anechoic chamber, during actual operation; these values are normally
somewhat different as a result of ambient condition.
The above design and specifications are subject to change without prior notice for product improvement.

Midea MSG-12HRIN2 Specifications

General

Brand	Midea
Model	MSG-12HRIN2
Category	Air Conditioner
Language	English
