Service manual
9
4. Specification
Ac Alfa，Ac Corona
Model MSH-18HRIN1 MSC-18HRIN1 MSE-09HRIN2 MSE-12HRIN2
Power supply Ph-V-Hz 1, 220-240V~, 50Hz 1, 220-240V~,50Hz 1, 220-240V~, 50Hz 1, 220-240V~, 50Hz
Capacity Btu/h 18000 18000 9000 12000
Input W 1670 1720 1100 1400
Rated current
9.0 7.5 5.1 6.4
Cooling
EER Btu/w.h 10.8 10.5, 8.2 8.6
Capacity Btu/h 20000 19000 12000 15000
Input W 1830 1790 1400 1700
Rated current
9.0 9.0
Model BA160X2CS-20KU BA160X2CS-20KU BG130X1C-20FZ BG130X1C-20FZ
Type Rotary Rotary Rotary Inverter Rotary Inverter
Brand TOSHIBA TOSHIBA TOSHIBA TOSHIBA
Capacity Btu/h 16140 16140 9468 9468
Input W 1630 1630 890 890
Rated current(RLA)
55 55
Thermal protector CS-74 CS-74 CS-74 CS-74
Capacitor uF No No No No
Compressor
Refrigerant oil ml 750 750 370 370
Model RPG28C RPG28C RPG13H RPG13D
Brand Welling Welling Welling Welling
Input W 45 55 39.5 44
Capacitor uF 1.5 1.5 1.2 1.5
Indoor \fan motor
Speed(hi/mi/lo) r/min 1200/1150/1000 1140/1060/980 1250/1100/850 1180/1000/850
Indoor air flow (Hi/Mi/Lo) m3/h 800/700/600 800/700/600 520/460/410 580/500/420
Indoor noise level (Hi/Mi/Lo) dB(A) 44/40/37 44/40/37 40/38/35 40/38/35
Model YDK53-6K YDK53-6C YDK24-6F YDK25-6-3
Brand Welling Welling Welling Welling
Input W 130 125 56 75
Capacitor uF 3.0 3.0 2.5 2.0
Outdoor fan motor
Speed r/min 750 800 800 900
Outdoor air flow m3/h 2500 2500 1600 1700
Outdoor noise level dB(A) 58 58 58 58
Refrigerant type R410A g 1650 1770 840 1200
Liquid side/ Gas side mm Ф6.35/Ф12.7 Ф6.35/Ф12.7 Ф6.35/Ф9.53 Ф6.35/Ф12.7
Max. pipe length m 10 15 10 10
Refrigerant piping
Max. in level m 5 8 5 5
Operation temp ℃ 17-30 17-30 17-30 17-30
Ambient temp ℃ -15-43 -15-43 -15-50 -15-50
Application area m2 28-45 28-45
Note:
The noise date is base on hemi-anechoic chamber, during actual operation; these values are normally
somewhat different as a result of ambient condition.
The above design and specifications are subject to change without prior notice for product improvement.
