Maintenance and
Disassembly
Page 56
Procedure Illustration
1) Remove the screws of the front right
panel and then remove the front
right panel (2 screws) (see CJ_D01_
INV_003).
2) Remove the screws of the front panel
and then remove the front panel (9
screws) (see CJ_D01_INV_004).
CJ_D01_INV_003
CJ_D01_INV_004
Note: This section is for reference only. Actual unit appearance may vary.
To Next Page
