Service manual
- 9 -
4 Operation limits
Cooling operation
Outdoor unit air temp. DB℃
Indoor air temp. DB℃
Note: The chart is the result from the continuous operation under constant air temperature
conditions. However, excludes the initial pull-down stage.
Heating operation
Indoor air temp. ℃ DB
Outdoor unit air temp.℃ DB
Note: The chart is the result from the continuous operation under constant air temperature
conditions. However, excludes the initial pull-down stage.
