Midea MV6-i730WV2GN1-E

V6-i VRF 50/60Hz
60
Midea V6-i Series Service Manual
2.2 Components
Layout 2.2.1
Figure 5-2.2: Outdoor unit main PCB components
Function of buttons SW3 to SW6 2.2.2
Table 5-2.2: Function of buttons SW3 to SW6
Button
Function
SW3 (UP)
In menu mode: previous and next buttons for menu
modes.
Not in menu mode: previous and next buttons for
system check information.
SW4 (DOWN)
SW5 (MENU)
Enter / exit menu mode.
SW6 (OK)
Confirm to enter specified menu mode.
