V6-i VRF 50/60Hz

Part

6 - Diagnosis and Troubleshooting

Procedure 2.8.5

xE9

The outdoor unit was powered on

immediately after being powered off

Yes

Power off the unit and wait for the digital

display to turn off before restarting the

unit

Replace outdoor main PCB

Notes:

1. When performing a manual restart of an outdoor unit, once the unit has been powered off it should not be powered on again until the digital display has

turned off.
