Midea RSJ-120/ZN1-540V1 User Manual

Midea R410A Direct Heating Type HPWH 50Hz Technical Manual MCAC-HTSM-201906
9
Table 2-1.2: RSJ-200/SZN1-540V1 specifications
Model name
RSJ-200/SZN1-540V1
Power supply
V/Ph/Hz
380-415/3/50
Water heating
1
Capacity
kW
20.4
Rated power input
kW
5.05
COP
4.04
Max. power input
kW
7.80
Max. input current
A
13.3
Compressor
Type
Scroll
Quantity
1
Capacity
kW
16.2
Input
kW
5.2
Rated current (RLA)
A
9.1
Locked rotor Amp (LRA)
A
74
Thermal protector
⁰C
135
Refrigerant oil
POE
Outdoor fan
Motor type
AC motor
Fan type
Axial fan
Number of fans
1
Speed (H/L)
r/min
900/580
Air flow
m
3
/h
≥5500
Air side heat exchanger
Type
Finned tube
Number of rows
2
Number of circuits
10
Water side heat exchanger
Type
Double-pipe heat exchanger
Material
Copper
Refrigerant
Type
R410A
Charged volume
kg
2.9
Throttle type
Electronic expansion valve
Outdoor noise level
dB(A)
63
Unit dimension (W×H×D)
mm
790×1100×810
Packing dimension (W×H×D)
mm
860×1220×885
Net/Gross weight
kg
157/172
Water piping connections Dia.
Mm
DN25
Water pressure drop
kPa
160
Wire controller
KJR-51/BMKE-A
Hot water yield
m
3
/h
0.45
Ambient temperature range
⁰C
-15 - 46
Water outlet temperature range
⁰C
48-60 (default)55
Notes:
1. The test conditions: outdoor temperature 20/15°C(DB/WB), inlet water temperature 15°C, outlet water temperature 55°C.
Midea CAC Confidential

Midea RSJ-120/ZN1-540V1 Specifications

General

Brand	Midea
Model	RSJ-120/ZN1-540V1
Category	Heat Pump
Language	English
