Midea RSJ-200/SZN1-540V1 - Introduction of Function Buttons; Specifications

MCAC-HTSM-201906 Midea R410A Direct Heating Type HPWH 50Hz Technical Manual
78
1 Specifications
Model
KJR-51/BMKE-A
Input Voltage
10.0V
Operating environment temperature
-10ºC~+43ºC
Operating RH
RH 40%~RH 90%
Performance Features
 Touch key operation.
 LCD displays operation parameters.
 Multiple timers.
 Real-time clock (battery life: 5~8 years).
2 Introduction of function buttons
The wired controller, KJR-51/BMKE-A, is universal controller, and some functions as reserved are not available for
this unit.
① Operation icon ( ): Indicate unit ON and OFF status; the icon displays when the unit is on and
does not display when the unit is off.
② Mode area: Indicate the main unit operating mode;
③ Setting temperature: 3 statuses can be displayed - .
