Midea SMK-D140HHN1-3

High Temperature Hydro Module
202003 19
Engineering Data
 Connection for other components
Coding
Assembly unit
Coding
Assembly unit
1
Connecting the wired controller
7
Connecting the circulating water
pump AC contactor
2
Free electrical signal
8
Connecting the AC contactor for
controlling water tanks and water
pumps
3
Cheap electrical signal
9
Connecting the three-way valve
4
Outdoor/MS units
communication .bus
10
Energy demand adjustment 1 input
5
Hydraulic module group control
interface/connecting to the KNX
gateway
11
Energy demand adjustment 2 input
6
Reserved
12
Alarm output -230 V~
1
CN15 CN17
CN20
CN21 SV3 CN22
N MSP1N NMSP2ALN.OY1 Y2
N N
N
X2X1 N2N1 M2M1 QP D2D1
C-PUMP
DHW-
PUMP
N.C
2 3 4 5
EE
6 7 8 9 10 11 12
{
{
{
{
{
{
{
{
{
{
{
{
