Midea SMK-D140HHN1-3

High Temperature Hydro Module
202003 23
Engineering Data
 Reserving Y1/Y2 at port
 Output control interface of the circulating water pump
 Output control interface of the water tank and water pump
Note: The circulating water pump, water tank and water pump are connected to an external contactor for control. Do not directly connect the water pump.
Voltage
220-240V
Maximum running current (A)
2
Wiring size (mm
2
)
2x0.75
Water
pump
