1.Removethefourshortscrews.

2.Insertthefourlongscrews.

Step2:installationofthepanel
Thewoodenpanelcanbeworkedaccordingtotheinstallationdrawings.
Fullyintegratedmodel
Attachthehooktothewoodenpanelandinsertthehookintotheslotofthe
outerdoorofthedishwasher(seefigureA).Afterpositioningthepanel,itis
fixedtotheouterdoorwithscrewsandbolts(seefigureB).




Step3:Adjustingthedoorspringtension

1.  Thedoorspringsareadjustedatthe
factorytothecorrecttensionforthe
outerdoor.Ifwoodenpanelsare
installed,youmustadjustthedoor
springtension.Turntheadjusting
screwtousetheadjustertotension
orloosenthesteelcable.
2.  Thedoorspringtensioniscorrectif
thedoorremainshorizontalinthe
fullyopenpositionbutfoldsupto
closewithalighttouchofthefinger.
