Midea TempMaker Series User Manual

MCAC-UTSM-2014-03 R410A 380~415V 3Ph 50Hz TempMaker Series Split AC
56
Model
MOV-192HN1-R
Power supply
\
380-415V~, 3Ph, 50Hz
Ambient temp in cooling
°C
17～46
Ambient temp in heating
°C
-7~24
Rated input (Outdoor unit)
W
32,200
Rated current (Outdoor unit)
A
53.8
Noise level
dB(A)
73
Compressor
Type ×Qty.
\
Scroll ×3
Brand
\
Hitachi
Model
\
E655DH-65D2YG(GC)
Capacity
W
17,100
Input
W
5,700
Rated current
A
9.6
Locked rotor Amp
A
64
Refrigerant oil
ml
500 (FVC68D)
Refrigerant type/charge
\
R410A/11,800g
Fan
Type ×Qty.
\
Axial fan ×2
Motor model
\
YDK380-4D
YDK450-6C
Motor input (4/3 fan blades)
\
580/420
724/399
Capacitor
\
20μF/450V
25μF/450V
Motor speed (4/3 fan blades)
rpm
Hi:1,090/Med:870(3 blades)
Hi:840/Med:550(4 blades)
Coil
Type
\
Copper tube and aluminum fin
Tube size
mm
Φ7.94
No. of rows
\
2
Fin space
mm
1.6
Tube pitch(a)×row pitch(b)
mm
22×19.05
Coil (W×H)
mm
3,155×1,232
Number of circuits
\
28
Refrigerant
pipe
Liquid side/ Gas side
mm
Ф16/Ф32
Max. pipe length
m
50
Max. difference in level
\
25m(O.D. up) /30m(O.D. down)
Connection
wire
Power wire
\
5×16.0mm
2
Signal wire
\
4×1.0mm
2
Dimension (W×H×D)
mm
1,390×1,615×765
Packing (W×H×D)
mm
1,455×1,790×830
Net/ Gross weight
kg
320/336
Notes:
1. Rated input = Max. input, Rated current = Max. current.
2. Nominal cooling capacities are based on the following conditions: Indoor temp: 27°CDB, 19°CWB; Outdoor
temp: 35°CDB; Nominal heating capacities are based on the following conditions: Indoor temp: 20°CDB;
Outdoor temp: 7°CDB, 6°CWB.
