5. Electric Characteristics
Model
Outdoor Unit
Power Supply
Compressor
OFM
Hz
Voltage
Min.
Max.
MCA
TOCA
MFA
MSC
RLA
KW
FLA
MOV-76HN1-R
50
380-415V
342V
440V
15.5
19.3
21.2
86
12.3
0.42
2.6
MOV-96HN1-R
50
380-415V
342V
440V
19.8
23.7
26.1
110
16.6
0.8
5.85
MOV-120HN1-R
50
380-415V
342V
440V
24.75
28.6
31.46
147
21.4
0.8
5.85
MOV-150HN1-R
50
380-415V
342V
440V
37.1
47.9
52.7
62
8.8
0.76
5.48
MOV-192HN1-R
50
380-415V
342V
440V
45.4
53.8
59.2
68
9.2
0.83
6.34
Remark:
MCA: Min. Current Amps. (A)
TOCA: Total Over-current Amps. (A)
MFA: Max. Fuse Amps. (A)
MSC: Max. Starting Amps. (A)
RLA: Rated Locked Amps. (A)
OFM: Outdoor Fan Motor.
FLA: Full Load Amps. (A)
KW: Rated Motor Output (kW)
6. Sound Levels
Front
h
H
1 m
Note: H = (h+1) / 2
Model
Noise level
MOV-76HN1-R
68 dB(A)
MOV-96HN1-R
68 dB(A)
MOV-120HN1-R
69 dB(A)
MOV-150HN1-R
70 dB(A)
MOV-192HN1-R
73 dB(A)
Microphone
