wiring according to the national rule.
 The appliance shall be installed in accordance with national wiring regulations.
7.2 Specifications of power supply
Type
Indoor unit
Outdoor unit
Model
MTB-76HWN1
MHB-76HWN1
MOV-76HN1-R
Power
220-240V~, 1Ph, 50Hz
380-415V~, 3Ph, 50Hz
Switch capacity of the main
power supply / Fuse
20A/10A
60A/40A
Indoor unit power cable
3×2.5mm
2
(Includes grounded wire)
\
Outdoor unit power cable
includes grounded wire
\
5×6mm
2
Connective wire of indoor and
outdoor unit
4×1.0mm
2
Wire controller connective wire
5×0.5mm
2
(Shield wire)
\
Type
Indoor unit
Outdoor unit
Model
MTB-96HWN1
MHB-96HWN1
MOV-96HN1-R
Power
220-240V~, 1Ph, 50Hz
380-415V~, 3Ph, 50Hz
Switch capacity of the main
power supply / Fuse
20A/10A
70A/50A
Indoor unit power cable
3×2.5mm
2
(Includes grounded wire)
\
Outdoor unit power cable
includes grounded wire
\
5×10mm
2
Connective wire of indoor and
outdoor unit
4×1.0mm
2
Wire controller connective wire
5×0.5mm
2
(Shield wire)
\
Type
Indoor unit
Outdoor unit
Model
MTB-120HWN1
MOV-120HN1-R
Power
220-240V~, 1Ph, 50Hz
380-415V~, 3Ph, 50Hz
Switch capacity of the main
power supply / Fuse
40A/20A
60A/40A
Indoor unit power cable
3×2.5mm
2
(Includes grounded wire)
\
Outdoor unit power cable
includes grounded wire
\
5×10mm
2
Connective wire of indoor and
outdoor unit
4×1.0mm
2
Wire controller connective wire
5×0.5mm
2
(Shield wire)
\
