Midea V8 Series

V8 Mini R410A VRF 50Hz
55
Part 2 - Outdoor Unit Engineering Data
10 Sound Levels
10.1 Overall
Table 2-10.1: Sound pressure level
Model
dB(A)
Height (m)
MV8M-80WV2N1
53
1
MV8M-100WV2N1
53
1
MV8M-120WV2N1
55
1
MV8M-140WV2N1
56
1
MV8M-160WV2N1
56
1
Notes:
1. Sound pressure level is measured at a position 1m in front of the unit and Hm above the floor in a semi-anechoic chamber. During in-situ operation, sound
pressure levels may be higher as a result of ambient noise.
Figure 2-10.1: Sound pressure level measurement (unit: m)
1m
H
