V8 Mini R410A VRF 50Hz
9
Part 1
-
General Information
DC Indoor Units
M
I
2
-
22
Q1
D
N1
1
2
3
4
5
6
8
Legend
No.
Code
Remarks
1
M
Midea
2
I
VRF indoor unit
3
2
Generation code
2: The 2nd generation
3: The 3rd generation
4
22
Capacity index (the capacity in kW multiplied by 10)
5
Q1
Indoor unit type
Q1: One-way Cassette
Q2: Two-way Cassette
Q4C: Compact Four-way Cassette
Q4: Four-way Cassette
T2: Medium Static Pressure Duct
T1: High Static Pressure Duct
G: Wall-mounted
DL: Ceiling & Floor
F: Floor Standing
6
D
Series category (D: DC series)
7
-
Power supply
Omit: 1 phase, 220-240V, 50Hz
H: 1 phase, 220-240V, 50/60Hz
8
N1
Refrigerant type (N1: R410A)
AC indoor units
MDV -
D
18
-
Q4 /
N1
E
(B)
1
2
3
4
5
6
7
Legend
No.
Code
Remarks
1
MDV
Midea
2
D
VRF indoor unit
3
18
Capacity index (the capacity in kW multiplied by 10)
4
Q1
Indoor unit type
Q1: One-way Cassette
Q2: Two-way Cassette
Q4C: Compact Four-way Cassette
Q4: Four-way Cassette
T2: Medium Static Pressure Duct
T1: High Static Pressure Duct
G: Wall-mounted
DL: Ceiling & Floor
F: Floor Standing
5
N1
Refrigerant N1: R410A
6
E
Design Code
7
(B)
Second Generation
