Midea V8 Series User Manual

V8 Mini R410A VRF 50Hz
125
Part 3
-
System Design and Installation
System Commissioning Report – Sheet D
Observed values
DSP1
content
Parameters displayed on DSP2
Remarks
Cooling
mode
Heating
mode
--.--
"Standby (ODU address+ IDU number)/frequency/special status"
0.--
Outdoor unit address
V8 Mini series outdoor unit: 0
1.--
Outdoor unit capacity (HP)
Actual value = value displayed
2.--
Number of outdoor units
V8 Mini series outdoor unit: 1
3.--
Number of indoor units set
Actual value = value displayed
4.--
Reserved
5.--
Target frequency of this ODU
Refer to Note 1
6.--
Reserved
7.--
Inverter compressor actual frequency (Hz)
Actual value = value displayed
8.--
Reserved
9.--
Operating mode
Refer to Note 2
10.--
Fan speed index (rpm)
Actual value = value displayed
11.--
Reserved
12.--
Indoor heat exchanger pipe (T2) average temperature (°C)
Actual value = value displayed
13.--
Indoor heat exchanger pipe (T2B) average temperature (°C)
Actual value = value displayed
14.--
Main heat exchanger pipe (T3) temperature (°C)
Actual value = value displayed
15.--
Outdoor ambient (T4) temperature (°C)
Actual value = value displayed
16.--
Liquid pipe (T5) temperature (°C)
Actual value = value displayed
17.--
Reserved
18.--
Plate heat exchanger outlet pipe (T6B) temperature (°C)
Actual value = value displayed
19.--
Inverter compressor A discharge (T7C1)temperature (°C)
Actual value = value displayed
20.--
Reserved
21.--
Inverter compressor A suction (T71) temperature (°C)
Actual value = value displayed
22.--
Reserved
23.--
Outdoor heat exchanger gas pipe(T8) temperature (°C)
Actual value = value displayed
24.--
Inverter module heatsink (Ntc)temperature (°C)
Actual value = value displayed
25.--
Reserved
26.--
Outdoor heat exchanger liquid pipe(TL)temperature (°C)
Actual value = value displayed
27.--
Discharge superheat degree (°C)
Actual value = value displayed
28.--
Primary current (A)
Actual value = value displayed /10
29.--
Inverter compressor A current (A)
Actual value = value displayed /10
30.--
Reserved
31.--
EEVA position
Actual value = value displayed × 24
32.--
Reserved
33.--
EEVC position
Actual value = value displayed × 4
Table continued on next page …
Project name and location
System name
