Midea VC Pro Series User Manual

VC Pro VRF 50/60Hz
190
Midea VC Pro Series Engineering Data Book
VC Pro Series System Commissioning Report – Sheet C
DSP1 content
Parameters displayed on DSP2
Remarks
Cooling
mode
0.--
Unit address
Master unit: 0; slave units: 1, 2
1.--
Unit capacity
Refer to Note 1
2.--
Number of outdoor units
Displayed on master unit PCB only
3.--
Number of indoor units as set on PCB
Displayed on master unit PCB only
4.--
Total capacity of outdoor unit
Only available for master unit,
displayed on slave units has no
sense
5.--
Total capacity requirement of indoor units
Displayed on master unit PCB only
6.--
Total corrected capacity requirement of master units
Displayed on master unit PCB only
7.--
Operating mode
Refer to Note 2
8.--
Outdoor unit actual operating capacity
9.--
Fan A speed index
Refer to Note 3
10.--
Fan B speed index
Refer to Note 3
11.--
Indoor heat exchanger pipe (T2/T2B) temperature (°C)
Actual value = value displayed
12.--
Main heat exchanger pipe (T3) temperature (°C)
Actual value = value displayed
13.--
Outdoor ambient (T4) temperature (°C)
Actual value = value displayed
14.--
Inverter compressor A discharge temperature (°C)
Actual value = value displayed
15.--
Inverter compressor B discharge temperature (°C)
Actual value = value displayed
16.--
Inverter module A heatsink temperature (°C)
Actual value = value displayed
17.--
Inverter module B heatsink temperature (°C)
Actual value = value displayed
18.--
Discharge superheat degree (°C)
Actual value = value displayed
19.--
Reserved
20.--
Reserved
21.--
EXVA position
Refer to Note 4
22.--
Compressor discharge pressure (MPa)
Actual value = value displayed × 0.1
23.--
Reserved
24.--
Number of indoor units currently in communication with
master unit
Actual value = value displayed
25.--
Number of indoor units currently operating
Displayed on master unit PCB only
26.--
Reserved
27.--
Silent mode
Refer to Note 5
28.--
Static pressure mode
Refer to Note 6
29.--
Reserved
30.--
Reserved
31.--
DC voltage A
Actual value = value displayed × 10
32.--
DC voltage B
Actual value = value displayed × 10
33.--
Reserved
34.--
Address of VIP indoor unit
Table continued on next page …
