7 Functional Components and Safety Devices
Table 2-7.1: 8-30HP functional components and safety devices
Item
8-30HP
Compressor
Compressor top and discharge pipe
temperature sensors
90°C = 5kΩ ± 3%
Inverter module
Inverter module temperature sensor
90°C = 5kΩ ± 5%
Fan motor
Limit temperature
On
115°C
Off
-
System
Low pressure switch
Off: 0.05 (±0.05) MPa / On: 0.15 (±0.05) MPa
High pressure sensor
Output voltage (V) = 1.1603 × P + 0.5
(where P is the discharge pressure in MPa)
Heat exchanger temperature sensor
25°C = 10kΩ
Outdoor ambient temperature sensor
25°C = 10kΩ
