Midland ALAN 42 MULTI User Manual

6
ENGLISH
6
FREQUENCY BAND CHART
Displayed digits Country
I
Italy 40 CH AM/FM 4Watt
I2
Italy 34 CH AM/FM 4Watt
D
Germany 80 CH FM 4Watt / 12 CH AM 1 Watt
D2
Germany 40 CH FM 4Watt / 12 CH AM 1 Watt
EU
Europe 40 CH FM 4Watt / 40 CH AM 1 Watt
EC
CEPT 40 CH FM 4Watt
E
Spain 40 CH AM/FM 4Watt
F
France 40 CH FM 4Watt / 40 CH AM 1 Watt
UK
England 40 CH FM 4Watt English frequencies
+ EC 40 CH FM 4Watt CEPT frequencies
ATTENTION!
The frequency band allowed all over Europe is 40CH FM 4W (EC) – See the
“Restrictions on the use” table.

Midland ALAN 42 MULTI Specifications

Power

power supply	7.2 ÷ 13, 2 nom 12V
current drain at standby	100 mA when the save mode is off, 45 mA when the save mode is on
current drain	900 mA

Receiver Specifications

sensitivity at 10dB S/N	0.5µV (AM), 0.25µV (FM)
selectivity	more than 60dB
audio output power	0.5W 8 ohm (10% distortion)

Transmitter Specifications

RF output power	duty cycle 10% 4W AM/FM
frequency tolerance	0.005%
harmonic suppression	more than 70 dB

Weight and Dimensions

dimensions	30x70x140 mm
weight	220 gr
