Midland ALAN 48 EXCEL MULTI User Manual

9
ENGLISH
SPECIFICATIONS
GENERAL
Channels ......................................................... 40 FM (see the Frequency band chart)
Frequency Range ......................................................................26.565 - 27.99125 MHz
Frequency Control ....................................................................................................PLL
Operating Temperature Range .....................................................................-10°/+55° C
DC input voltage ................................................................................13.2/24 Vdc ±15%
Size ..................................................................................... 150(L) x 45(H) x 175(D)mm
Weight .......................................................................................................................1Kg
RECEIVER
Receiving system ......................................................Dual conversion superheterodyne
Intermediate frequency ................................................ I°IF:10.695 MHz II°IF:455 KHz
Sensitivity ...................................................................0.5µV for 20dB SINAD in AM/FM
Audio output power @10% THD ........................................................... 2.0 W @ 8 Ohm
Audio distortion ...........................................................................Less than 8% @ 1KHz
Image rejection ........................................................................................................65dB
Adjacent channel rejection ......................................................................................65dB
Signal/Noise ratio ....................................................................................................45dB
Current drain at stand/by .........................................................................13.2V: 450mA
..................................................................................................................... 24V: 520mA
TRANSMITTER
Output power ....................................................duty cycle 10% 4W AM/FM @ 13.2 Vdc
Modulation ...................................................................................... FM:1.8KHz ± 0.2khz
.............................................................................................................. AM: 85% to 95%
Frequency response ..............................................................................400 Hz ÷ 3 KHz
Output impedance .................................................................... RF 50 Ohm unbalanced
Signal/Noise Ratio .........................................................................................40 dB MIN
Current drain ........................................................13.2V: 1300 mA (without modulation)
..................................................................................24V: 1600mA (without modulation)
All specications are subject to change without notice.

Midland ALAN 48 EXCEL MULTI Specifications

Operating Environment

operating temperature range	-10°/+55° C
frequency range	26.565 - 27.99125 MHz
frequency control	PLL

Power

dc input voltage	13.2/24 Vdc ±15%
current drain at standby (13.2V)	450mA
current drain at standby (24V)	520mA

Receiver Specifications

receiving system	Dual conversion superheterodyne
intermediate frequency	I°IF:10.695 MHz II°IF:455 KHz
sensitivity	0.5µV for 20dB SINAD in AM/FM

Transmitter Specifications

output power	duty cycle 10% 4W AM/FM @ 13.2 Vdc
modulation	FM:1.8KHz ± 0.2khz AM: 85% to 95%
frequency response	400 Hz ÷ 3 KHz

Weight and Dimensions

size	150(L) x 45(H) x 175(D)mm
weight	1Kg
