7
ENGLISH
INSTALLATION
Safety and convenience are the primary consideration for mounting any piece of mobile
equipment. All controls must be readily available to the operator without interfering with
the movements necessary for safe operation of the vehicle. Set the proper position in
the car to install the transceiver using the supplied supporting bracket or eventually the
slide bracket. Tighten the retaining screws. The xing bracket must be close to metallic
parts.
POWER SUPPLY
Be sure the transceiver is off. In the direct-voltage power supply, to observe the polarity
is very important, even if the unit is protected against the accidental inversion:
Red = positive pole (+)
Black = negative pole (-)
The same colors are present on the battery and in the fuse box of the car. Connect
correctly the cable terminal to the battery.
ATTENTION
To obtain best performances we recommend to install the radio in a place with
enough air circulation.
INSTALLING AN ANTENNA
1. Place the antenna as high as possible.
2. The longer is the antenna, the better will be the performance.
3. If possible, mount the antenna in the center of whatever surface you choose.
4. Keep the antenna cable away from noise sources, such as the ignition switch,
gauges,etc.
5. Make sure you have a solid metal-to-metal ground connection.
6. Prevent cable damage during antenna installation.
WARNING. to avoid damage, never operate your CB radio without connecting a
proper antenna. A periodical control of the SWR is recommended.

Other manuals for Midland ALAN 48 EXCEL MULTI

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Midland ALAN 48 EXCEL MULTI and is the answer not in the manual?

Midland ALAN 48 EXCEL MULTI Specifications

Operating Environment IconOperating Environment
operating temperature range-10°/+55° C
frequency range26.565 - 27.99125 MHz
frequency controlPLL
Power IconPower
dc input voltage13.2/24 Vdc ±15%
current drain at standby (13.2V)450mA
current drain at standby (24V)520mA
Receiver Specifications IconReceiver Specifications
receiving systemDual conversion superheterodyne
intermediate frequencyI°IF:10.695 MHz II°IF:455 KHz
sensitivity0.5µV for 20dB SINAD in AM/FM
Transmitter Specifications IconTransmitter Specifications
output powerduty cycle 10% 4W AM/FM @ 13.2 Vdc
modulationFM:1.8KHz ± 0.2khz AM: 85% to 95%
frequency response400 Hz ÷ 3 KHz
Weight and Dimensions IconWeight and Dimensions
size150(L) x 45(H) x 175(D)mm
weight1Kg
