Midland G7 User Manual

Midland G7 Pro user’s manual | 23
Technical specifications
Channels 1~8 PMR, 1~69 LPD
Frequency range 446.00625 ÷ 446.09375MHz
(PMR)
433.075 ÷ 434.775MHz (LPD)
Channel spacing 12.5 KHz (PMR); 25 KHz (LPD)
Power supply 6+/- 10% Vdc
Temperature from -20° to +55°C
Dimensions (w/o batteries) 58 (L)x 122 (H)x34 (D) mm
Weight (w/o batteries) 123gr
Duty cycle TX 5%, RX 5%, stand-by 90%
Category B
Transmitter
Output power 10 or 500 mW (Selectable)
Modulation FM
Spurious rejection within European legal terms
Receiver
Sensitivity @ 12dB Sinad 0,35µV
Adjacent channel rejection 70dB
Audio output power 300mW @ 10% THD
Jack for ext.mike and recharge stereo 2,5 mm
Jack for ext. speaker mono 3.5 mm
Maximum transmission time
in an hour
6 minutes, equivalent
to a duty cycle of 10%
Specifications are subject to change without notice.
WARNING: Direct plug-in ac/dc power supply must be used for disconnecting the
transceiver from the mains; the desktop charger must be positioned close to the
unit and easily accessible.

Midland G7 Specifications

General

VOX Function	Yes
Display	LCD
Operating Temperature	-20°C to +55°C
Frequency Range	446.00625 - 446.09375 MHz
Weight	123 grams (without batteries)
Power Supply	Battery or AC adapter
