Midland G9/G9E Plus instruction guide | 11
Refer to this picture to identify the various parts of the device
15. Built-in speaker Here is where the speaker is housed.
16. MENU button Press this button to enter the radio’s MENU.
17.
CALL/
CALL
MENU
EMG
15
24
23
22
21
20
19
18
17
16
3
2
1
14
13
12
10
9
11
8
7
6
5
4
button
To send a CALL on the selected channel. If you keep
it pressed for about 5 seconds, the keypad lock is
activated.
18. PTT (push to talk) The PTT key has a dual function, as it is composed
by 2 parts: the larger and bigger side of the PTT key,
allows the transceiver to send with high or low power
(depending on the setting of the MENU); while the
small PTT (Boost) allows the transceiver to transmit
always with high power.
19. VOLUME knob On/o and VOLUME adjustment.
20. ANTENNA Receives and transmits radio signals.
21. Accessory socket (under protective cover) To connect to external
audio devices such as microphones, chargers, etc.
(2pin type)
22. EMG button To activate the Emergency and the Manual Out of
range functions.
23.
▲▼ buttons
To change the setting within the MENU
24. Built-in
microphone
Here is where sound is picked up by the microphone.
