THEORY OF OPERATION
70-050/055
Crystal XI generates a stable reference frequency for IC3
generation and detection. IC 4 functions as an audio highpass filte
remove CTCSS tones from the speaker audio. Encode tone output is
IC3 pin 16 with tone modulation level adjustable by RV1.
tone
r to
from
14
