XT70 PRO user’s manual | 5
1. Antenna
2. OFF/VOLUME knob - To switch on/o the radio and to adjust the vol-
ume.
3. MENU - Press shortly this control to enter the radios menu. Keep it
pressed for 3 seconds to send out the emergency call.
4. CALL/ – to send a call to the selected channel. If you keep it pressed for
about 3 seconds, the keypad lock is activated.
5. ▲/ -▼ controls - To change the settings in the menu. If you keep pres-
sed ▲/ you manually verify if there are some radios within the range
(manual Out of range function).
6. MIC - Built-in microphone
7. Built-in Speaker.
8. MON/SCAN - Press this button once to activate SCAN. Keep it pres-
sed for about 2 seconds to activate the Monitor function, that tempora-
rily cuts o the squelch (for weak signals)
9. PTT - Press to transmit.
10. SPK | MIC (under the protective cover) - To connect to external audio
devices such as microphones, headphones, etc
11. Battery compartment: insert the rechargeable battery pack supplied in
the package.
