MN3024DIY
User Manual
For Lithium Battery :
Battery type
Parameters
Ternary
lithium
battery
(N
06
)
Ternary
lithium
battery
(N
07
)
Lithium
iron
phosphate
battery
(LF
0
7)
Lithium
iron
phosphate
battery
(LF
0
8)
Lithium
iron
phosphate
battery
(LF09)
User
-
defined
(User)
Overvoltage
disconnection
voltage
30V 30V 30V 30V 33V 18～30V
Equalizing
charge voltage
24.6V
(Adjustable)
28.7V
(Adjustable)
24.6V
(Adjustable)
28.4V
(Adjustable)
31.8V
(Adjustable)
18～30V
Absorbtion charge
voltage
24.6V
(Adjustable)
28.7V
(Adjustable)
24.6V
(Adjustable)
28.4V
(Adjustable)
31.8V
(Adjustable)
18～30V
(Adjustable)
Float
charge voltage
24.6V
(Adjustable)
28.7V
(Adjustable)
24.6V
(Adjustable)
28.4V
(Adjustable)
31.8V
(Adjustable)
18～30V
(Adjustable)
Undervoltage
alarm voltage
19.2V
(Adjustable)
22.4V
(Adjustable)
21.6V
(Adjustable)
24.8V
(Adjustable)
27.8V
(Adjustable)
18～30V
(Adjustable)
Low voltage
disconnection
voltage
18.0V
(Adjustable)
21.0V
(Adjustable)
21V
(Adjustable)
24.4V
(Adjustable)
27.4V
(Adjustable)
18～30V
(Adjustable)
Discharge limit
voltage
16.8V 19.6V 20.4V 24.2V 27.2V
18～30V
(Adjustable)
Over-
discharge
delay time
30s
(Adjustable)
30s
(Adjustable)
30s
(Adjustable)
30s
(Adjustable)
30s
(Adjustable)
1～30s
(Adjustable)
Equalizing
charge
duration
- -
- - -
0～600
minutes
(Adjustable)
Equalizing
charge interval
- -
- - -
0～250
days
(Adjustable)
Absorption charge
duration
120
minutes
(Adjustable)
120
minutes
(Adjustable)
120
minutes
(Adjustable)
120
minutes
(Adjustable)
120
minutes
(Adjustable)
10～600
minutes
(Adjustable)
