Real-time data viewing method
On the LCD main screen, press the “UP” and “DOWN ”
buttons to scroll through the real
-time data
of the machine.
Page
Parameters on the left side of the
screen
Parameters
in the
middle of
the screen
Parameters on the right
side of the screen
1
INPUT BATT V
(Battery input voltage)
Fault code
OUTPUT LOAD V (Output
load voltage)
2
PV TEMP ℃
(PV charger heatsink temperature)
PV OUTPUT KW
(PV output power)
3
PV INPUT V
(PV input voltage)
PV OUTPUT A
(PV output current)
4
INPUT BATT A
(Input battery current)
OUTPUT BATT A
(Battery output current)
5
INPUT BATT KW
(Battery input power)
OUTPUT BATT KW
(Battery output power)
6
AC INPUT Hz
(AC input frequency)
AC OUTPUT LOAD Hz
(AC output frequency)
7
AC INPUT V
(AC input voltage)
AC OUTPUT LOAD A
(AC output load current)
8
INPUT V
(For maintain )
OUTPUT LOAD KVA
(Load apparent power)
9
INV TEMP ℃
(AC charge or battery discharge
heatsink temperature)
INV OUTPUT LOAD KW
(Load active power)
10 APP software version Bootloader software version
11 Model PV Voltage Rating Model PV Current Rating
12 Model Battery Voltage Rating Model Outp ut Power Rating
4.2 Setup parameters description
Buttons operation instructions: Press the “SET” button to enter the setup menu and exit the
setup menu. After entering the setup menu, the parameter number [00] will flash. At this
point, press the “UP” and “DOWN” buttons to select the code of parameter item to be set.
Then, press the “ENT” button to enter the parameter editing mode, and the value of the
parameter is flashing. Adjust the value of the parameter with the “UP” and “DOWN” buttons.
Finally, press the “ENT” button to complete the parameter editing and return to the
parameter selection state.
