10-527-1 MN3024DIY REV A
MN3024DIY
User Manual
Parameter
no.
Parameter
name
Settings Description
00
Exit setting
menu
[00] ESC Exit the setup menu
01
Output source
priority
[01] SOL
PV priority mode, switching to the Mains when
the PV fails or the battery is lower than the set
value of parameter [04].
[01] UTI default
Mains priority mode, switching to inverter only
when the mains fail.
[01] SBU
Inverter priority mode, switching to the mains
only when the battery is under voltage or lower
than the set value of parameter [04].
02
Output
Frequency
[02] 50.0
Bypass self-adaptation; when the mains are
connected, it automatically adapts to the mains
frequency; when the mains iare disconnected, the
output frequency can be set through this menu.
The default output frequency of the 230V
machine is 50HZ, and the 120V machine 60HZ.
[02] 60.0
03
AC Input
Voltage
Range
[03] APL
Wide mains input voltage range of 230V
machine: 90~280V
Mains input voltage range of 120V machine:
90~140V
[03] UPS default
Narrow mains input voltage range of 230V
machine: 170~280V
Mains input voltage range of 120V machine:
90~140V
04
Battery Power
to Utility
Setpoint
[04] 23.0 default
When the parameter [01] =SOL/SBU, the
battery voltage is lower than the set value, and
the output is switched from the inverter to the
mains. Setting range: 22V~26V.
05
Utility to
Battery Power
Setpoint
[05]28.0V
default
When the parameter [01] =SOL/SBU, the
battery voltage is higher than the set value, and
the output is switched from the mains to the
inverter. Setting range: 24V~30V.
