MidNite MN3024DIY - Page 38

38 of 39
10-527-1 MN3024DIY REV A
MN3024DIY
User Manual
All-in-one solarchargeinverter38
Battery
voltage range
20 –33Vdc
Maximum
output powe
r
1400W
PV charging
current range
(can be set)
0-60A
Charging
short circuit
protection
fuse
Wiring
protection
Reverse polarity protection
Hybrid charging Max charger current specifications (AC charger+PV charger)
Max charger
current (settable) 0-100A
Certified specifications
Certification CE(EN62109-1)
EMC
certification
level
EN61000, C2
Operating
temperature
range
-15°C to 55 °C
Storage
temperatur
e
range
-25°C ~ 60°C
Humidity
range
5% to 95% (Conformal coating protection)
Noise ≤60dB
Heat
dissipation
Forced air cooling, variable speed fan
Communicati
on interface
USB/RS485(Bluetooth/WiFi/GPRS)/Dry node control
Size (L*W*D) 378mm*280mm*103mm
Weight (kg) 6.2
